6DE-18

Auxiliary system

6DE-18

6DE-18 
e-Diesel

Environmentally Friendly Engine

We have developed the environmentally friendly economical engines for energy saving, low maintenance cost and have a high potential for meeting stricter exhaust gas regulations in the future, of course IMO Tier 2 compliant. These engines realized the environmental harmony and high performance by long-held technologies of DAIHATSU DIESEL.

6DE-18 Specifications

Engine model Unit 6DE-18
Cylinder Diameter mm 185
Stroke mm 280
No. of Cylinders   6
Engine Revolutions min-1 720 900
Engine Output kWm 680 860
Generator Output kWe 645 820
Overall Length(*1) mm 4,850
Overall Width(*2) mm 1,070
Overall Height(*3) mm 2,400
Piston Overhaul Height(*4) mm 2,300
Generator Set Dry Mass(*5) kg 12,000

*1 Varies depending on the generator.
*2 The maximum width of the common baseplate mounting surface.
*3 The height of the exhaust port from the common baseplate mounting surface.
*4 The height from the common baseplate mounting surface.
*5 Varies depending on the generator.

Power Chart
